Optical Mirrors Optical Lenses for Industrial Lasers and Medical Equipment

Fuzhou O-Zone Optics is Customized Optics manufacturer:Plano-Convex Cylindrical  Lens is widely use in optical display systems, projection optics systems, imagining optical systems, and laser measurement systems. It is best use where conjugate point-- object distance, S or image distance S\' is more than five time

Featured Products

Fuzhou O-Zone Optics is Customized Optics manufacturer:
Plano-Convex Cylindrical  Lens is widely use in optical display systems, projection optics systems, imagining optical systems, and laser measurement systems. It is best use where conjugate point-- object distance, S or image distance S' is more than five times of the other. This lens is almost the most super form for both collimating a point source and focusing collimated light;
Plano-Concave acaylindrical  Lens has a negative focal length and is typically used to cause a collimated beam to diverge as in a Galilean type beam expander or Telescope. Because the spherical aberration of the Plano-Concave is negative, it can be used to balance the aberration of other lenses.This lens is widely use in optical display systems, projection optics systems, imaging and laser measureemnt systerms;
End Caps is a high-power device designed for high-power fiber laser and amplifier output End face processing. It reduces the optical power density of the output End by expanding the output beam.



Our main lens
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment

Important parameters
AttributeCommercialHigh Precision
Typical MaterialBK7BK7 , Fused Silica
Typical Dimension X*Y (mm)10*1010 * 30
Diameter Tolerance (mm)+0.00/-0.2+0.00/-0.2
Focus Length Tolerance(mm)Typical +/-2%@633nmTypical +/-2%@633nm
Centration ( arc min)Typical  < 3Typical  < 3
Surface Figure X (per 25mm@632.8nm)1 /2 1/4
Surface Figure Y(per 25mm@632.8nm)λ
Surface Quality (scatch/dig)60-4010-5
Bevel (face width * 45° mm)0.2--0.50.05-0.2
coatingwavelength:AR: R≤0.25% per surface broadband AR R≤0.5% per surfaceAs requested

Our factory:

Advanced equipments and complete production system ensure the whole production process.
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment



Inspection capacity:

strictly control during the production process and final inspection.

Optical Mirror Optical Lens for Industrial Laser and Medical Equipment
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment


Coating machine:
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment


Our certificates:
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment


Exhibition


The laser photonic exhibition in Shanghai in 2019 has won high praise form our customers both from home and abroad.
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment
Optical Mirror Optical Lens for Industrial Laser and Medical Equipment


Logistics

In order to make the goods safe fast accurate to your hands, we generally recommend that you choose the international logistics company!

Optical Mirror Optical Lens for Industrial Laser and Medical Equipment

Contacts:

Sunny. Pan










Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
